Example of parameters to send data via RMAP
protocol.
The protocol requires that each measurement is
configured with the WMO parameters (§2.2.4.1).
The password is visible in the configuration file.
2.2.6.6 LSI LASTEM CLOUD protocol
Configuration example for sending data to the LSI
LASTEM cloud.
Then proceed with the assignment of the identification
keys of each configured measure.
For more information refer to the CLOUD_04842
manual.
LSI LASTEM provides upon request the Cloud Service data recording and processing system. For
more information contact the commercial service by writing to info@lsi-lastem.com.
2.2.6.7 Modbus RTU Slave protocol
Example of parameters to send data via Modbus RTU
protocol using the COM3 RS-485 port(10).
For more information, read ISTUM_03762 user’s
manual.
2.2.6.8 Modbus TCP Slave protocol
Example of parameters to send data via Modbus TCP
protocol using a network connection.
For more information, read INSTUM_03763 user’s
manual.
2.2.7 HTTP and FTP server configuration
2.2.7.1 HTTP server
Alpha-Log has an internal http web server. Using an Internet browser, it will possible to access to the http
pages made by the data logger. Pages are used for data display, diagnostic information and data download
from the memory (§4.2.9).
