LSI LASTEM Alpha-Log - Operating Status Leds; Menu Navigation

Alpha-Log – User manual
LSI LASTEM SRL
INSTUM_03388
Page 86 / 116
In other screenshots:
➢ In Serial lines (§5.1.4.2) screenshot, change the serial port number.
➢ In Events screenshot, move to the previous or the next event.
If display is off (low power mode):
Turns the display on.
I display is on (normal mode):
If being hold for some seconds, turns the display off.
5.1.3 Operating status LEDs
On Alpha-Log’s front panel are 3 LEDs that indicates the instrument operative status: Rx/Tx, Wrk, Batt.
Rx/Tx
This LED, green, lights up when communication activity is ongoing on any serial port.
Wrk
This LED, green, lights up to indicate any measurement activity of signals connected to the instrument; it also
briefly lights up if an event is registered by a possible connected pluviometer.
Batt
This LED is red and has the following meanings:
- Steady on: voltage is present from FV module and battery is not charged or it’s disconnected.
- Flashing: voltage is present from FV module and battery is connected and charged.
- Off: voltage is not present from FV module or battery charged.
5.1.4 Menu navigation
From MAIN menu, the user can access Alpha-Log’s several submenus.
M
A
I
N
>
L
o
g
g
i
n
g
D
i
a
g
n
o
s
t
i
c
S
y
s
t
e
m
M
a
i
n
t
e
n
a
n
c
e
A
d
v
a
n
c
e
d
f
e
a
t
u
r
e
s
