Part 3
3.1 ALIEM (Alpha-Log Input Extension Module)
ALIEM is a module used to extend the number of sensors managed by Alpha-log. It measures the instant
values from the sensors connected (it does not perform any statistical processing) and makes them available
to Alpha-Log through the Modbus RTU protocol on the RS-232 port (3).
ALIEM looks like in Fig. 3.
Fig. 3 – ALIEM description.
(1) - On/Off switch
(2) - Com1 serial port (PC)
(3) - Com2 serial port (Alpha-Log)
(4) - Operating status LEDs
(5) - Keyboard
(6) – Terminal board
