18 The GS550 System
4. Press Enter to get the sensor firmware product and version numbers.
5. Press Exit five times to return to the operation display.
Radio Network Diagnostic
1. Press Menu → Back → Enter → Next → Enter to go to menu 5B1) Radio network back-
ground noise.
W
ARNING
! The “list of last 32 sensors received” includes all functioning GS series sen-
sors within range. Programming a GS550 display for sensors from a different system
will disable that system and render indication by both systems inaccurate.
2. Press Next to go to menu 5B2) List last 32 sensors received.
a. Press Enter to access 5B21), the list of the last 32 sensors received. Sensors are
shown with their radio id number and the sensor type.
b. Use Up and Down to scroll through the list.
c. Press Exit to return to menu 5B2)
3. Press Next to go to menu 5B3) Search for sensors.
a. Press Enter to launch a sensor search. After searching, the display automatically reverts
to 5B21), the list of the last 32 sensors received (see step 2.a).
4. Press Next to go to menu 5B4) Bit error rate communication test. This test should only be
conducted by LSI technical service personnel.
5. Press Exit three times to return to the operation display.
Figure: Sensor firmware product and version numbers
Product number Version number
Sensor type
Sensor value Battery level
Power received by the display
Figure: Sensor diagnostic data
Power emitted
Internal temperature
