66 The GS550 System
Example of having two usernames on
the same PC. One is “LSI” and the
other one is “lsi”. This can be confusing
and must be verified when there is
difficulty copying to the Palm.
How to free up memory
1) Power up the Palm. With the plastic
pen, press on the Home icon on the
lower left side of the screen until an icon
called “LS420 Download” is visible.
2) Press on the LS420 Download icon. A
list of available files will be displayed.
3) Press on the file to be deleted
4
Press on the delete button
Trouble Shooting PDA Communication Issues
Copy to a PDA when using several PDAs with the same PC
1. Transfer a firmware to a PDA
a. Click on the mouse
right-button over the
file in an Explorer
window. Then select
“Send To”… and “PDA
Quick Install”. See the
picture below.
b. Or… double-click on
the firmware received
in an email.
2. Usually a window will pop up
to confirm the addition of this file
to the list of files to be transferred
to a PDA. Verify the “User” in this
window. Two or more “users”
may be configured to the PC.
Verify PDA memory.
1. Power up the PDA. With the
plastic pen, press on the Home
icon on the lower left side of the
screen to see the time of day on
the upper left.
2. Press on the time of day, a menu
should pop up, press on <Info…>
in this menu. A page will show
how much free memory is
available on the PDA.
Example:
1.1M means 1.1 megabytes,
equates to 1100 kb (kilobytes). Each
GS550 firmware uses more than 140 kb of
memory. If there is not enough memory
left, verify if some applications or data
logger files could be removed.
Note: A firmware with crane capacity charts may
require more memory.
The PDA doesn’t respond. If the PDA doesn’t appear to respond to commands or if prob-
lems occur during a transfer operation then the PDA can be reset by pressing the reset but-
ton on the back. All applications will then restart; data should not be lost.
