Installation 25
Table: Lockout Codes
Condition Code
Maximum wind speed 1
Minimum angle 2
Maximum angle 4
Overload 8
Not used 16
Maximum radius 32
Maximum length 64
Two-block 128
Maximum wind gust 256
Maximum rope payout 512
Condition Code
Minimum slew 1024
Maximum slew 2048
Maximum tip height 4096
Maximum imbalance factor 8192
Minimum slack rope 16384
Minimum list angle 32768
Maximum list angle 65536
Minimum trim angle 131072
Maximum trim rope 262144
Examples:
Maximum wind speed 1
Maximum angle 4
Overload 8
Maximum length 64
Two-block 128
Maximum tip height + 4096
Default white wire trigger = 4301
Maximum radius 32
Minimum angle + 2
Default green wire trigger = 34
Lockout relay inversion. By default the lockout wires carry crane power supply voltage
as long as the display is in safe condition. When lockout is triggered voltage is cut on the
lockout wires linked to the lockout condition.
Warning! Inverting lockout relays will allow crane operation in the event the GS550
display fails. Operating a crane without a functioning anti-two-block system and load
and angle indication is dangerous and may be against the law.
Exceptionally the lockout relay can be inverted so that lockout wires carry no voltage in safe
condition and carry crane power supply voltage when in a triggered lockout condition. In
this case if the display fails, crane functions will not lockout.
1. Press Menu → Next → Next → Next → Enter → Next → Next → Next→ Next →
Next → Next → Enter → Back to access menu 4G8) Lockout relay inverted.
2. Use Up and Down to switch between “yes” and ”no”.
3. Exit three times to return to the operation display.
Password Settings
Three levels of access are available: administrator, operator and public. The administrator pass-
word is required to change the operator password. In the event both the administrator and the
operator passwords are lost please call your LSI representative. Menus accessible from the
operation display can be individually protected by the operator password.
1. Press Menu → Next → Next → Next → Enter → Next → Next → Next→ Next → Next →
Next → Next to access the menu 4H1) Set administrator password.
2. 4H1) Set administrator password: Press Next three times to advance to the set user password
page or, to change the administrator password, use Up and Down to adjust the flashing letter
and then use Next to advance to the next letter. Press Enter to save any changes.
