Installation 39
1. Press Menu → Next → Next → Next to go to menu 4)
Installation.
2. Press Enter → Next to go to menu 4B) Sensor Calibra-
tion.
3. Press Enter to go to the password page.
4. Use Back, Next, Up, and Down to enter the user pass-
word, and then press Enter to go to 4B1) Automatic
Value Calibration Wizard.
5. Press Enter to go to 4B1A).
6. Use Back and Next to select the length sensor, and then
press Enter to confirm communication with the sensor is
possible.
7. Press Next to start the wizard.
8. Note the units that will be used during the calibration
wizard, and then press Next.
9. Fully retract the boom, and then press Next.
10. Use Up and Down to adjust the length value displayed to
equal the actual fully retracted boom length, and then
press Next.
11. Fully extend the boom, and then press Next.
12. Use Up and Down to adjust the length value displayed to
equal the actual fully extended boom length, and then
press Next.
13. Note the new trim value, and then press Next.
14. Note the new scale value, and then press Next.
15. Press Enter to send the new calibration to the length
sensor.
16. Press Exit three times to return to the operation display.
Operation Display
1) Parts of Line
2) Crane Rigging
3) Display Settings
Enter user password:
aaa
4B1) Automatic value
calibration wizard
4B1A) No. x id: Gxxxxx
Length sensor
Communicating with
remote sensor
Length calibration
wizard. Press Next.
1/8) Confirm current
units: (feet, metres)
2/8) Retract boom to
min length: xx.x
3/8) Adjust actual
boom length: xx.x
4/8) Extend boom to
max length: xxx.x
5/8) Adjust actual
boom length: xxx.x
6/8) Calib Result
Trim: xx.x
7/8) Calib Result
Scale: x.xxxx
8/8) Press Enter to
save calib in sensor
4A) Sensor List
4) Installation
4B) Sensor Calibration
Figure: The boom length
calibration wizard.
