Chapter
12
Instal
lation and
W
iring
12
−
11
(b)
Don’t
install like the following figure
(5
)
Distan
ce
with oth
er device
To avoid radi
ation noise or heat,
k
eep the di
stanc
e
betw
een PLC and device (conn
ector and rel
a
y) as far
as the fol
lowing figure.
D
evice ins
ta
lled in f
ron
t of PLC
: 100
㎜
or above
Device in
s
talled be
side PLC: 50
㎜
or above
100mm
or above
50mm
or above
50mm
or above
159
