Appendix 2 Communication Relay List (L)
A-２
(2) High-speed Link 2
Device IEC type Keyword Type Description
High-speed link parameter 2 normal operation of all station.
L0260 %LX416 _HS2_RLINK Bit
Indicates normal operation of all station according to parameter set in
High-speed link and On under the condition as below.
1. In case that all station set in parameter is Run mode and no error
2. All data block set in parameter is communicated and
3.The parameter set in each station itself is communicated normally.
Once RUN_LINK is On, it keeps On unless stopped by
LINK_DISABLE.
Abnormal state after _HS2RLINK On.
L0261 %LX417 _HS2_LTRBL Bit
In the state of _HSmRLINK flag On, if communication state of the
station set in the parameter and data block is as follows, this flag
shall be On.
1. In case that the station set in the parameter is not RUN mode, or
2. There is an error in the station set in the parameter, or
3. The communication state of data block set in the parameter is not
good.
LINK TROUBLE shall be On if the above 1, 2 & 3 conditions occur,
and if the condition return to the normal state, it shall be OFF again.
High speed link parameter 1, k block general state.
L0280 ~
L031F
%LX448
~
%LX511
_HS2_STATE[k]
(k = 00~63)
Bit
Array
Indicates the general state of communication information for each
data block of setting parameter.
_HS2_STATE[k]=HS2MOD[k]&_HS2TRX[k]&(~_HS2_ERR[k]
)
High speed link parameter 1, k block station RUN operation mode.
L0320 ~
L035F
%LX512
~
%LX575
_HS2_MOD[k]
(k = 00~63)
Bit
Array
Indicates operation mode of station set in k data block of parameter.
Normal communication with High speed link parameter 1, k block
station.
L0360 ~
L039F
%LX576
~
%LX639
_HS2_TRX[k]
(k = 00~63)
Bit
Array
Indicates if communication state of k data of parameter is
communicated smoothly according to the setting.
High speed link parameter 1, k block station operation error mode.
L0400 ~
L043F
%LX640
~
%LX703
_HS2_ERR[k]
(k = 00~63)
Bit
Array
Indicates if the error occurs in the communication state of k data
block of parameter.
High speed link parameter 1, k block setting.
L0440 ~
L047F
%LX704
~
%LX767
_HS2_SETBLO
CK[k]
Bit
Array
Indicates whether or not to set k data block of parameter.
