Appendix 2 Communication Relay List (L)
A-３
(3) Common area
Communication flag according to P2P service setting
In case of XGB, P2P parameter is 1~3, P2P block is 0~31.
Device IEC type Keyword Type Description
L5120 %LX8192
_P2P1_NDR0
0
Bit
Indicates P2P parameter 1, 0 Block service
normal end.
L5121 %LX8193
_P2P1_ERR0
0
Bit
Indicates P2P parameter 1, 0 Block service
abnormal end.
L513 %LW513
_P2P1_STAT
US00
Word
Indicates error code in case of P2P parameter 1, 0 Block
service abnormal end.
L514 %LD257
_P2P1_SVCC
NT00
DWord
Indicates P2P parameter 1, 0 Block service
normal count.
L516 %LD258
_P2P1_ERRC
NT00
DWord
Indicates P2P parameter 1, 0 Block service
abnormal count.
L5180 %LX8288
_P2P1_NDR0
1
Bit
P2P parameter 1, 1 Block service normal end.
L5181 %LX8289
_P2P1_ERR0
1
Bit
P2P parameter 1, 1 Block service abnormal end.
L519 %LW519
_P2P1_STAT
US01
Word
Indicates error code in case of P2P parameter 1, 1 Block
service abnormal end.
L520 %LD260
_P2P1_SVCC
NT01
DWord
Indicates P2P parameter 1, 1 Block service
normal count.
L522 %LD264
_P2P1_ERRC
NT01
DWord
Indicates P2P parameter 1, 1 Block service
abnormal count.
L524~L529
%LW524
~
%LW529
- Word P2P parameter 1,2 Block service total.
L530~L535
%LW530
~
%LW535
- Word P2P parameter 1,3 Block service total.
L536~L697
%LW536
~
%LW697
- Word P2P parameter 1,4~30 Block service total.
L698~L703
%LW698
~
%LW703
- Word P2P parameter 1,31 Block service total.
