LTV 1150 - Page 337

p/n 18603-001, Rev. C LTV
®
1200/1150 Ventilator Service Manual Page F-3
CONFIG · 6-39
CONFIG EXIT · 6-39
CONTROL · 2-6
DATA · 6-8
EVENT TRACE · D-1
EXIT · 2-11, 6-41
FLOW DIFF · 6-11, 6-12
LEAK · 2-8
LOCKED · 7-4
MOTOR DRIVE · 6-20
O2 INLET · 6-19
PPP · 6-18
REMOVE PTNT · 2-2, 6-8
RESET · 6-34
SERVO OFF · 6-31
SERVO ON · 6-31
TCOMP · 6-38
TCOMP ON · 6-38
VALVE DIFF · 6-14, 6-17
VENT CHECK · 2-2
VENT MTNCE · 6-6, 6-8, 6-41
VENT OP · 6-8
VER · 8-89
WDOG TEST · 6-34
XDCR FAULT · 7-14
displays
airway pressure display window · 2-5
blank · 7-4
control display windows · 2-7
dim · 7-4
dot-matrix window · 2-4
LED window · 2-4
E
EASY · 7-5
EEPROM, clearing · see clear, EEPROM
EMC · iii
ESD · 6-27, 7-32, 7-36, 7-37, 8-3
ET tube · 7-43
event
codes · D-3
trace · D-1
events, clearing · see clear, events
exhalation drive line · 7-11
EXP HOLD · A-1
expiratory hold · A-1
extended features
factory default settings · E-11
map · E-2
external accessories
screw type, length and location · E-5
F
factory defaults · E-11
fan assembly ·
8-63
fan connector · 8-71,
8-74
filters
external inlet · 8-62
fan · 4-2,
8-64
inlet · 4-3
internal inlet · 8-81
O
2
inlet · 4-4, 8-100
oxygen blender · 8-100
wet or damp · 4-5,
8-64
final checkout tests
12 hour burn-in checkout test · 9-30
general checkout test · 9-2
oxygen checkout test · 9-28
performance checkout test · 9-15
power checkout test · 9-11
finish washers · 8-8
flow differential
bi directional (FDb) · E-17
calibration · 6-12
narrow (FDn) · E-17
wide (FDw) · E-17
flow performance · 6-27
FLOW TERM · 7-2
flow valve
assembly · 8-65
calibration · 6-27
configuration · 6-27
configuration · 6-37
connector · 8-71
field calibration · 6-27
home position · 6-37
incorrect valve home position ·
6-37
stepper motor · 6-33
VHome · 6-37
flow valve differential (FVd) · E-17
forms
service record · C-1
front panel · 8-71
G
general checkout
worksheet ·
9-8
general test ·
9-2
grounded anti-static wrist strap · 8-3
grounding clips, position and orientation · 8-
96, 8-131
H
HARD · 7-5
heatsink pads · 8-125, see thermo conductive
pads
high flow transducer test · 6-10
