Page F-4 LTV
®
1200/1150 Ventilator Service Manual p/n 18603-001, Rev. C
HIGH O2 PRES · 7-3
HIGH PEEP · 7-37
HIGH PRES · 7-2
HP DELAY · 7-32
HW FAULT · 4-2, 7-22, 7-34,
8-64
I
inlet filter · 4-3
INSP HOLD · A-1
inspiratory hold · A-1
Inspiratory/Expiratory · E-11
inspiratory/expiratory hold · A-1
installation
LTM mounting assembly (current model) ·
8-20
internal battery · 8-77
internal inlet filter · see filter: internal inlet
J
JP8, connector · 8-68
K
keypad ribbon cable · 8-73, 8-83
L
leak
test · 2-8,
9-2
low flow transducer test · 6-10
LOW MIN VOL · 7-3
LOW O2 PRES · 7-3
LOW PRES · 7-3
LTM compatibility test · 9-22
LTM/LTV
®
mounting assembly (current LTM) ·
8-16
M
main board · 8-82
mounting screws · 8-84
standoffs · 8-84
maintenance
10,000 hour/2 year · 5-3
30,000 hour/6 year · 5-3
calibration · 6-8
daily · 5-2
dusty or high humidity environments · 5-2
monthly · 5-2
preventative · 5-1
storage · 5-2
ventilator maintenance tests · 6-6
maintenance mode DIP ·
6-25
manifold and blender · 8-95
map, extended features · E-2
measured T/S value · See turbine speed
turbine speed · 6-23
mechanical shock · 6-27
membrane switch panel · 8-73
align ·
8-74
memory · 6-40
board · 8-88
MODEL · 7-3, 7-4
model selection · 6-36
motor board · 8-90
motor drive calibration · 6-21
MRI equipment · iii
N
clear · 6-40
notes
definition · 1-2, 2-3, 2-7, 2-10
O
O
2
blender · see oxygen blender
O
2
blender filter · see oxygen blender filter
O
2
inlet filter · 4-4, see oxygen blender filter
O
2
inlet port cap · 4-4
O
2
inlet pressure calibration · 6-19
orange seal · 8-97, 8-132
orange tube · 8-69
oxygen blender · 8-92
barbed fitting · 8-95
mounting · 8-96, 8-131
oxygen checkout
worksheet · 9-29
oxygen checkout test · 9-28
oxygen pressure O
2
· E-17
oxygen pressure transducer · 8-58
P
parts, replacement · E-7
patient assist call system · 7-38
patient circuit components · 4-6
patient circuits · 4-6
patient outlet pressure test · 9-19
PC FLOW TERM · 7-2
PCBA
analog · 8-57, 8-59
main · 8-82
memory · 8-88
motor · 8-90
