Table 8.3-2 —
Netra
240 Terminal Locations
SAI No. AW PCI SLOT No.
SAI PORT TTYC PORT
TTYC No.
01 2 2 11
01 3 3 11
01 4 2 12
01 5 3 12
01 6 2 13
01 7 3 13
10 0 2 14
10 1 3 14
10 2 2 15
10 3 3 15
10 4 2 16
10 5 3 16
10
6
a
NA NA
10
7
b
NA NA
Note(s):
a. SAI 1 Port 6 is reserved for the MTTY on a Netra 240.
b. SAI 1 Port 7 is reserved for the ROP on a Netra 240.
(c) Type and enter: i
Note: When growing a TTY terminal a defensive check failure message
REPT CONFIG FAULT Assert = 412 may be received. This failure message
may be ignored.
4. Install the STLWS to the SAI port corresponding to the TTYC port and TTYC
number chosen in Tables 8.3-1 and 8.3-2 (see Figure 8.3-1 , 8.3-2) and 8.3-3.
(a) Enter CARRIAGE RETURN
GROWTH AND DEGROWTH
Procedure 8.3
235-200-150
October 2005
Page 8.3-4 Issue 3.01
