Lucent 5ESS DRM User Manual

A1. SUN
1
CONSOLE/MASTER CONTROL CENTER (MCC) TERMINAL SETTINGS
A1.1 Overview
Table A1-1 lists terminal settings that should be set when growing a KS-23996 Sun
console or MCC terminal. Table A1-1 should also be used to verify terminal option
settings in the case of a terminal lock-up.
Table A1-1 — KS-23996
Sun Console/MCC Terminal Settings
Session 1 (MCC-EIA)
F1 Screen
Emulation = VT100 Comm Mode = Full Duplex EIA Baud Rate = 9600
Aux Baud Rate = 9600 Enhanced = off EIA Data Format = 7/1/E
Format = 8/1/N Sessions = 2 Host/Printer = EIA/None
F2 Screen
Emulation = VT100 Enhanced = off Auto Wrap = on
Auto Font Load = on Auto Pager = off Auto Scroll = on
Monitor Mode = off Screen Saver = off Bell Volume = 09
Warning Bell = on Host/Printer = EIA/None Sessions = 2
Session 2 (Sun Console-AUX)
F1 Screen
Emulation = VT100 Comm Mode = Full Duplex EIA Baud Rate = 9600
Aux Baud Rate = 9600 Enhanced = off EIA Data Format = 7/1/E
Format = 8/1/N Sessions = 2 Host/Printer = AUX/None
F2 Screen
Emulation = VT100 Enhanced = off Auto Wrap = on
Auto Font Load = on Auto Pager = off Auto Scroll = on
Monitor Mode = off Screen Saver = off Bell Volume = 09
Warning Bell = on Host/Printer = AUX/None Sessions = 2
Session 1/2
F3 Screen
Page Length = 24 Screen Length = 26 Lines Screen Video = Normal
Display Cursor = on Cursor = Steady Black Auto Adjust Cursor = on
Columns = 80 Width Change Clear = off Speed = Normal
F4 Screen
Char Set Mode = ANSI Key Mode = ASCII Keyclick = off
Key Repeat = off Margin Bell = off Key Lock = Caps
F5 Screen
Enter Key = <CR> Return Key = <CR> Backspace = <BS>/<BS>
Alt Key = Alt ,< and .> = < and .> Esc Key = Esc
’~ Key = ’ and ~ F1 to F5 Keys = Fkeys Pound Key = U.S.
F6 Screen
1. Registered trademark of Sun Microsystems, Inc.
235-200-150
August 2003
APPENDIX 1
SUN CONSOLE/MASTER CONTROL CENTER (MCC)
TERMINAL SETTINGS
Issue 3.00 Page A1-1
