Table 2-10 — Emergency Action Interface (EAI) Maintenance Commands (Contd)
COMMAND DESCRIPTION
55
c
Loads selected disk from tape unit 0.
57 Same as 54 plus reboots the 3B21 emulator.
58 Same as 57 plus reboots Solaris System V Release 4 OS
59 Stops the 3B21 emulator, thus stopping the AM.
Note(s):
a. Commands 30 through 43 generate the next state of the maintenance
teletypewriter (MTTY) peripheral control information which is sent to the
processor the next time commands 50 through 55 are executed.
b. Commands 51 through 55, in addition to the description given, cause the current
next state information to be sent to the processor.
c. Command 55 requires a disk unit to be selected (commands 20 or 22).
2.9.5.3 MCC Page 111/112 - AM, AM Peripherals
The purpose of the 111/112 display page is to report the status of the AW (shown as
AM on the screen) and its peripherals. The AW peripherals are the MHDs, MT, MTTY,
ROP and the link to the switching module.
Figure 2-34 is an example of the DRM version of the 111/112 display page. Note that
all restore pokes are executed with the unconditional (UCL) option.
Figure 2-34 — MCC Display Page 111,112 AM, AM Peripherals
235-200-150
Feburary 2007
5ESS
®
SWITCH DISTINCTIVE REMOTE MODULE
Issue 3.00O Page 2-43
