2.9.5.7 MCC Page 1190 - MCTSI Status
The purpose of the 1190 page display is to show status and provide maintenance
commands for the Module Controller/Time Slot Interchanger (MCTSI) and the
external timing references. Figure 2-38 shows the 1190 page.
When an off-normal condition occurs, the indicator for the condition backlights. On
Page 1010,X, the MCTSI indicator backlights. On Page 114, the indicator for the
switching module backlights; and on the appropriate 141, 142, 143, or 144 page, the
indicator for the switching module backlights, and a phrase describing the problem is
written, unless a more critical condition exists. In the SUMMARY STATUS AREA, the
switching module critical indicator and the alarm level (CRITICAL, MAJOR, or
MINOR), if applicable, are backlighted.
SYS EMER CRITICAL MAJOR MINOR BLDG/PWR BLDG INH CKT LIN SYS NORM
OVERLOAD SYS INH AM AM PERPH OS LINKS SM CM MISC
CMD< 124 - DCI/ASM STATUS PAGE
REMOVE: 20X DCI-0
ACT
RESTORE: 30X
DIAGNOSE: 50X
ASM-0 ACT
Figure 2-37 MCC Display Page 124
5ESS
®
SWITCH DISTINCTIVE REMOTE MODULE 235-200-150
Feburary 2007
Page 2-48 Issue 3.00O
