The MCTSI status data is stored in the switching module.
2.9.5.7.1 Commands
Commands are given to remove, restore, and diagnose the MCTSI or external timing
references and to switch the MCTSI or to force active the MCTSI. Any available
paging commands can be entered from the 1190 page.
CMD RESULT
20X MCTSI X is removed. (RMV:MCTSI=SM#-X) [,UCL]
23XY MCTSI X REF Y is removed (RMV:SMREF=SM#-X-Y)
30X MCTSI X is restored. (RST:MCTSI=SM#-X) [,UCL]
[,STBY]
33XY MCTSI X REF Y is restored. (RST:SMREF=SM#-X-Y)
50X MCTSI X is diagnosed. (DGN:MCTSI=SM#-X,RAW,TLP)
[,UCL] [,GROW]
[,RPT] Test is repeated 32,767
times.
[,RPT=a] The "a" is the number of
times the test is to be repeated
(1-32,767).
[,PH=b|b&&c] The "b" is the
diagnostic phase or "b&&c" is the
range of phases to be performed.
63XY MCTSI X REF Y is inhibited. INH:HDWCHK,SMREF=SM#-X-Y
73XY MCTSI X REF Y is allowed. ALW:HDWCHK,SMREF=SM#-X-Y
40x MCTSI X is forced active.
SYS EMER CRITICAL MAJOR MINOR CKT LIM SYS NORM
OVERLOAD SYS INH AM AM PERPH OS LINKS SM MISC
CMD< 1190 - SM 050 DRM MCTSI
20X MCTSI
23XY MCTSI X REF Y NORMAL
SITE 000
30X MCTSI X
33XY MCTSI X REF Y
50X MCTSI X 63XX MCTSI X REF Y
MCTSI 0 MCTSI 1
ACT STBY
403 MCTSI 73XY MCTSI X REF Y
REF 0 REF 1 REF 0 REF 1
40X SET MCTSI X ACT STBY STBY STBY
402 CLR FORCE
REMOVE SM 050 STAT
RESTORE
DIAGNOSE INHIBIT
SWITCH ALLOW
FORCE ACTIVE
Figure 2-38 — MCC Display Page 1190
235-200-150
Feburary 2007
5ESS
®
SWITCH DISTINCTIVE REMOTE MODULE
Issue 3.00O Page 2-49
