Connection Instructions 33
Selecta
PBL200051, Rev J
Connect the footswitch (optional)
The Selecta provides a choice of laser activation. By default, the laser is
activated by the joystick laser pushbutton. However, many physicians prefer
footswitch activation, and Lumenis provides a footswitch that may be used
with the system. If the footswitch is used, plug the footswitch cable into the
footswitch receptacle, as shown.
If a footswitch is connected, the Footswitch laser activation mode must also be
selected on the options screen of the laser remote control, as described in the
“Laser Basics—Remote Control” section of this manual.
If the footswitch is selected on the options screen remote control, but is not
properly connected when the laser is turned on, (footswitch not
connected) displays on the remote control display and the laser cannot be
placed in ready mode.
