PC (external photocoagulator) Mode—remote control screen

Remote control

(PC mode shown)

Error message display

Laser mode

display

PC Mode

indicator

Laser mode

selector

Options toggle

(on top side)

Contrast knob

(on top side)

Illumination mirror

indicator
