MacDon D50 - Safety Decal Locations

169441 9 Revision D
1.7 Safety Decal Locations
Safety signs are usually yellow decals, and are placed on the machine where there is a risk of personal injury, or where the
operator has to take extra precaution before operating controls.
1003348
A
A
A
Figure 1.15: Upper Cross Auger – Older Version
A - MD #174682
NOTE:
The Upper Cross Auger (UCA) kits have changed over the years, and the safety decals installed on the augers have changed
also. Refer to the appropriate illustration for the UCA installed on your header.
SAFETY
