4.12.3 Maintenance Record
Log hours of operation, use the maintenance record, and keep copies of your maintenance records.
Maintenance
Record
Action:
üü - Check
SS - Lubricate
▲▲ - Change
Hour Meter Reading
Date
Serviced by
First Use, refer to 4.12.1 Break-in Inspection, page 241
End of Season, refer to 3.22 Storing the Header, page 111
10 Hours or Daily
5
ü
Hydraulic hoses and lines
6
ü
Knife sections, guards, and
hold-downs
ü
Tire pressure
S
Knife (except in sandy
conditions)
25 Hours
S
Knifehead(s)
50 Hours
S
Draper roller bearings
S
Knife drive shaft bearings
(double-knife headers)
S
Knife drive box oil - first 50
hours only
S
All upper cross auger (UCA)
grease points
100 Hours or Annually
ü
Reel drive chain tension
ü
Reel tine/cutterbar
clearance
ü
Knife drive belt tension
ü
Wheel bolt torque
ü
Knife drive box
lubricant level
ü
Knife drive box
mounting bolts
250 Hours or Annually
S
Reel drive U-joint
S
Transport axle pivot
bushings
MAINTENANCE AND SERVICING
5. Whichever occurs first.
6. A record of daily maintenance is not required, but can be kept at the Owner’s/Operator’s discretion.
