2.2 Specifications
Use the specification table to reference information about a machine’s specific configuration. The table lists dimensions,
weights, performance ranges, and features.
Table 2.1 Header Specifications
Header Model
D60
D50/D60
D60
Header Size
4.6 m
(15 ft.)
6.1 m
(20 ft.)
7.6 m
(25 ft.)
9.1 m
(30 ft.)
10.7 m
(35 ft.)
12.2 m
(40 ft.)
Conveyor (Draper) and Decks
Draper width
1057 mm (41.6 in.)
Draper drive Hydraulic
Draper speed
0–225 m/min. (0 –742 fpm)
Delivery opening
D50
Not applicable
1710–1920 mm (67.3–75.6 in.)
Not
applicable
D60
1540–1770 mm
(60.61–69.7 in.)
1720–1950 mm (67.1–76.7 in.)
Height
945–1058 mm (37.2–1058 mm)
Draper angle
(cutterbar on the
ground)
D50 & D60
13.0–18.4°
Reel
Reel drive Hydraulic from windrower hydraulic oil supply
Reel speed
0–62 rpm
Quantity of tine tubes
6 or 9 D50: 5 or 6; D60: 9 5 or 6
5
Effective reel diameter
1650 mm (65 in.)
Finger tip radius range
766–800 mm (30.2–31.5 in.)
Finger type
Plastic
—
Standard
Heavy-duty
plastic
Standard Optional D60
—
Finger spacing
152.4 mm (6 in.)
Upper Cross Auger (Optional)
Outside diameter
305 mm (12 in.)
Weight
61 kg
(34 lb.)
74 kg
(163 lb.)
87 kg
(192 lb.)
100 kg
(221 lb.)
113 kg
(250 lb.)
127 kg
(279 lb.)
Stabilizer Wheels (Optional)
Size
Not applicable
ST205 / 75R-15
Pressure
Not applicable
Load range E: 552 kPa (80 psi)
Load range D: 415 kPa (60 psi)
Weight Not applicable
91 kg (200 lb.)
NOTE:
Specifications and design are subject to change without notice or obligation to revise previously sold units.
NOTE:
Weights do not include options.
