169441 246 Revision D
5.1.3 Hydraulic Reel Fore-Aft Positioner
The Hydraulic Reel Fore-Aft Positioner allows the Operator to control the reel fore-aft position from the windrower cab.
This option is available only for headers that were not factory-equipped with the hydraulic reel fore-aft option.
Figure 5.3: Hydraulic Reel Fore-Aft Positioner
Installation and adjustment instructions are included with
the kit.
• Single-reel headers: MD #B5205
• Double-reel headers: MD #B5206
OPTIONS AND ATTACHMENTS
