Figure 1.26: Backtube – 7.6–12.1 m (25–40 ft.) Export Headers
1-9.1–12.2 m (30–40 ft.) D50 and D60 Export Headers 2 - 7.6 m (25 ft.) D60 Export Header 3 - 7.6–12.2 m (25–40 ft.) D50 and D60 Export Headers
A - MD #174432 B - MD #174434 C - MD #174474
D - MD #113482
