215620 161 Revision A
Figure 5.80: Forming Shield bracket – R85
Figure 5.81: Forming Shield bracket – R2 Series
30. If switching to an R85 or R2 Series Rotary Disc Header,
retrieve the forming shield support brackets (A) from the
toolbox, and attach the brackets as follows:
a. install support bracket (A).
b. Install hardware (B) to secure the support to the
windrower leg.
c. Repeat on the opposite windrower leg.
ATTACHING A HEADER TO THE WINDROWER
