Figure 5.235: Grass Seed Hydraulic Connections –
M1240 Rotary Disc Configuration

$
%
Figure 5.236: Left Cab-Forward Platform
7. Push latch (A) to unlock platform (B).
ATTACHING A HEADER TO THE WINDROWER
