215620 226 Revision A
Figure 5.243: Center-Link
16. Windrowers WITH center-link self-alignment kit: Release
center-link latch (A) before returning to the cab.
DANGER
Ensure that all bystanders have cleared the area.
17. Start the engine.
18. Remove header float when prompted by the Harvest Performance Tracker (HPT).
NOTE:
If not prompted by the HPT to remove float, remove float manually.
Figure 5.244: GSL
19. Use HEADER TILT cylinder switches (A) on GSL to release
load on center-link cylinder.
20. Windrowers WITH center-link self-alignment kit: Operate
the link lift cylinder with REEL UP switch (B) to disengage
the center-link from the header. Proceed to Step 24, page
227.
ATTACHING A HEADER TO THE WINDROWER
To Next Page
