MacDon M1 Series - Page 79

215620 67 Revision A

$
%
&
'
Figure 3.51: Left Platform Steps
19. Insert two bolts (A) into platform and hook steps (B) onto
the bolts.
20. Install lock clips (C) with tabs in the slots and secure with
nuts (D). Torque bolts to 95 Nm (70 lbf·ft).
ASSEMBLING WINDROWER
