MAINTENANCE/SERVICE
Form 169469/169470/169471 171 Revision C
7.10.3 FIELD LIGHTS: CAB-FORWARD
DANGER
Stop engine and remove key from ignition
before leaving operator's seat for any
reason. A child or even a pet could engage
an idling machine.
7.10.3.1 Adjustment
The field lights are best adjusted with the
machine in the field or the equivalent to suit
operator preference.
a. Hold onto the hand-holds (A) on the cab front
corners and stand on the header anti-slip strips.
b. Adjust the lights with screws (B).
7.10.3.2 Bulb Replacement
a. Remove the two screws (C) and remove light
assembly.
b. Replace the bulb as described in Section
7.10.2.2.
