OPERATOR’S STATION
Form 169469/169470/169471 29 Revision C
5.13 RADIOS
5.13.1 AM/FM RADIO
A radio is available as optional equipment from
your dealer and a space (A) is provided in the
cab headliner to accommodate the installation.
Two pre-wired speakers (B) have been factory
installed in the headliner. Refer to M150 &
M200 Self-Propelled Windrower Unloading and
Assembly Instruction for radio installation
procedures. Operating instructions are supplied
with the radio.
5.13.2 ANTENNA MOUNTING
A roof mounted antenna base for installing a
magnetic antenna is available as an option from
your dealer. Order part #160288, or see
illustration for part dimensions for a “homemade”
version. It accommodates most CB, 2-way radio
and satellite radio antennas. A knockout for the
antenna lead is provided on the cab post
IMPORTANT
Antenna base can only be installed on the
LH and RH rear cab roof bolts.
5.14 HORN
The horn is activated by pushing the button
located on the panel in the headliner. The
ignition switch must be on. Sound the horn
three times prior to starting the engine.
REMOVE EXISTING BOLT AND
REINSTALL WITH ANTENNA BASE
