OPERATOR’S STATION
Form 169469/169470/169471 53 Revision C
5.18.6 SETTING GUIDELINES
5.18.6.1 Pressure Settings
HEADER MODEL APPLICATION/SYSTEM
SUGGESTED OVERLOAD
WARNING SETTING
psi (kPa)
WINDROWER PRESSURE
DIFFERENTIAL RELIEF SETTING
psi (kPa)
R80/R85 Disc Pressure 5000 (34474) 5800 (39990)
D-SERIES
A-SERIES
Reel/Draper Pressure 3000 (20684) 3500 (24132)
Knife/Conditioner Pressure 4000 (27579) 4500 (31026)
5.18.6.2 R Series Rotary Header Disc Speeds
CROP CONDITION DISC RPM *
Alfalfa
Heavy 2100-2300
Light 1800-2000
Sudan, Sorghum,
Haygrazer,
Timothy
Tall &
Stemmy
2300-2500
Short Grass
Dense 2500
Thin 2000-2200
* Suggested Overload Setting – 1300 rpm.
5.18.7 ENGINE ERROR CODES
The CDM displays “Error Codes” when there is a
fault with one of the several sensors that monitor
and control engine operation, to assist the
operator or technician in locating a specific
problem with engine operation. Refer to the
Appendix for the “Error Codes”.
5.18.8 CDM & WCM FAULT CODES
The CDM displays “Fault Codes” when there is a
fault with one of the several sensors that monitor
and control windrower operation, to assist the
operator or technician in locating a specific
problem with the windrower. Refer to the
Appendix for the “Fault Codes”.
