MacDon M205 2010 - Windshield Wipers; Rear View Mirrors; Cab Temperature; Heater Shut-Off Valve

OPERATOR’S STATION
Form 169469/169470/169471 26 Revision C
5.8 WINDSHIELD WIPERS
The windshield wiper controls are located in the
cab headliner. The illustration above designates
the controls as in the cab-forward mode.
5.9 REAR VIEW MIRRORS
Two adjustable outside mounted mirrors provide
rear view vision when the windrower is operated
in the cab-forward mode. A single interior
mounted mirror provides rear view vision in the
engine-forward mode.
5.10 CAB TEMPERATURE
The cab environment is controlled by a climate-
control system that provides clean air-
conditioned or heated air for the operator. The
heater/evaporator/blower assembly is located
under the cab floorboard and is accessible from
beneath the windrower.
5.10.1 HEATER SHUT-OFF VALVE
A shut-off valve at the engine allows the cab
heater to be isolated from the engine coolant.
The valve must be open to provide heat to the
cab but for maximum cooling, the valve can be
closed.
5.10.2 AIR DISTRIBUTION
Cab air distribution is controlled through
adjustable air vents. They are located in the cab
posts to provide window and operator ventilation
as shown in illustration.
OPEN
CLOSE
DIRECTION
REAR VIEW MIRRORS
CAB FORWARD
REAR VIEW MIRROR
ENGINE-FORWARD
FRONT WIPER SWITCH
Controls Front Windshield Wiper
ON/OFF
REAR WIPER SWITCH
Controls Rear Windshield Wiper
ON/OFF
HEATER SHUT-OFF VALVE
OPEN – Counterclockwise
CLOSE - Clockwise
