OPERATOR’S STATION
Form 169469/169470/169471 22 Revision C
5.4 TRAINING SEAT
A wall mounted fold-up training seat complete
with seat belt is provided for use as described
below. To lower seat, lift latch (A) and lower
seat (B). For storage, lift seat (B) and secure
with latch (A).
WARNING
The training seat is provided for an
experienced operator of the machine when a
new operator is being trained.
The training seat is NOT intended as a
PASSENGER SEAT or FOR USE BY
CHILDREN.
USE THE SEAT BELT whenever operating
the machine or riding as a trainer.
KEEP ALL OTHER RIDERS OFF THE
MACHINE.
5.5 SEAT BELTS
The windrower is equipped with a seat belt on
the Operator’s and Trainer’s seats.
WARNING
Before starting engine, securely fasten your
seat belt and ensure trainer’s seat belt is
fastened if occupied. The seat belt can help
insure your safety if it is used and
maintained.
Never wear a seat belt loosely or with slack
in the belt system.
Never wear the belt in a twisted condition or
pinched between the seat structural
members.
a. To fasten seat belt, pull belt completely across
your body. Push the metal eye into the buckle
until it locks. Adjust the position of the belt as
low on your body as possible.
b. To release, push the red button in the end of the
buckle and separate the buckle and metal eye.
5.6 STEERING COLUMN ADJUSTMENT
The steering column can be adjusted to suit
each particular operator and for easier entry to
and exit from the seat.
a. Hold onto steering wheel, lift handle (C), and
move steering wheel up or down to desired
position.
b. Release handle (C) to lock steering wheel
position.
