MacDon M205 2010 - Reel Speed

HEADER OPERATION – A SERIES
Form 169469/169470/169471 110 Revision C
6.6.4 REEL SPEED
6.6.4.1 A40-D Header
The A40 reel drive is hydraulically driven and is
dependent on the auger and knife speeds.
IMPORTANT
To prevent overspeeding the auger,
initially set the speed of the reel and auger
as follows: Subsequent adjustments to
reel speed do not affect auger speed.
YES
##.## = 15.00 – 85.00
ENGAGE HEADER
HEADER INDEX
SWITCH - OFF
ON GSL PRESS SLOW
DISPLAY SHOWS
##.## REEL RPM
DONE
SPEED
15.00?
NO
YES
ON CDM PRESS SLOW
OR FAST ON AUGER
DISPLAY SHOWS
##.# AUGER SPEED
NO
ON GSL PRESS SLOW
OR FAST
DISPLAY SHOWS
##.## REEL RPM
NO
YES
SPEED
OK?
##.# = 4.7 – 9.9
4.7 = 150 rpm
* 9.9 = 320 rpm
##.## = 15.00 – 85.00
SPEED
OK?
