MacDon M205 2010 - Specifications

PRODUCT DESCRIPTION
Form 169469/169470/169471 15 Revision C
4.2 SPECIFICATIONS
ENGINE
Type
Cummins QSB-6.7L 6 Cylinder Turbo Diesel. B20 Bio-Diesel Approved.
Displacement
409 cu.in. (6.7 L)
Power
Rated
220 hp (164 kW) @ 2200 rpm
Peak
230 hp (172 kW) @ 2000 rpm
Bore
4.21 in. (107 mm)
Stroke
4.88 in. (124 mm)
Maximum RPM (no load)
2250-2340
Idle RPM
1075-1150
ELECTRICAL SYSTEM
Recommended Battery (2)
12 Volt, Min. 750CCA, Max Dim – 13x6.81 x9.43 in. (334x188x232 mm).
Group Rating 29H or 31A. Heavy Duty/Off Road/Vibration Resistant.
Alternator
130 amp
Starter Wet Type
Working Lights 11
TRACTION DRIVE
Type
Hydrostatic, 3 Speed Electric Shift
Speed
Field (Cab Fwd)
Lo Range 0-11 mph (18 km/h)
Mid Range 0-16 mph (26 km/h)
Reverse (Cab Fwd)
6 mph (9.6 km/h)
Transport (Engine Fwd)
High Range 0-23 mph (37 km/h)
Transmission
Type
2 Piston Pumps – 1 per Drive Wheel.
Displacement
2.65 cu.in. (44 cc)
Flow
40 U.S. gpm (167 L/min)
Final Drive
Type
Planetary Gearbox
Ratio
30.06 : 1
Wheel Motor Displacement
Lo Range
4.15 cu.in. (68 cc)
Mid Range
3.01 cu.in. (50 cc)
Hi Range
1.93 cu.in. (32 cc)
SYSTEM CAPACITIES
Fuel Tank 97 U.S. Gallons (367 L)
Cooling 7.9 U.S. Gallons (30 L)
Hydraulic Reservoir 17.2 U.S. Gallons (65 L)
HEADER DRIVE
Type
Hydraulic, Electrical Displacement Control
Displacement
Piston Pump A – 6.44 cu.in. (105.5 cc.), Gear Pumps B & C – 1.02 cu.in. (16.7
cc.)
Flow
Piston Pump A – 72 gpm (0-273 L/min), Gear Pumps B & C – 12 gpm (45 L/min)
Max Pressure
Piston Pump
Gear Pump B
Gear Pump C
Disc Drive
6000 psi (414 bar)
---
---
Knife Drive
4000 psi (276 bar)
---
---
Reel Drive
3200 psi (221 bar)
---
DWA Drive
---
2600 (179)
---
Conveyor
---
---
2600 (179)
Supercharge
---
300 psi (20.7 bar)
(continued next page)
