PRODUCT DESCRIPTION
Form 169469/169470/169471 16 Revision C
Type
Hydraulic Double Acting Cylinders. Tilt – Hydraulic Positioning, Optional
Mechanical Link
Gear Pump
1.02 cu.in. (16.7 cc)
12 U.S. gpm (45 L/min)
System Pressure (Relief/Max)
2500 psi (172 bar)
Primary Adjustment
Manual, External, Draw-Bolt With Springs (1 per side). One Inner Booster
Spring On Left Side.
Fine Adjustment Hydraulic, In-Cab Switch
Automatic
Hydraulic, 3 Programmable Settings For All Headers (Deck Shift
Compensation On Draper Headers)
Type Spring/Shock Suspension
Dimensions
Width
63 in. (1600 mm)
Depth
68.3 in. (1735 mm) (at top of window)
Height
64.6 in. (1640 mm)
Volume
125 cu.ft. (3540 L)
Seat
Driver
Adjustable Air-Ride Suspension, Seat Belt
Training
Folding, Cab Mounted, Seat Belt
Windshield Wiper
Front
31.5 in. (800 mm) Blade
Rear
22 in. (560 mm) Blade
Heater
24,000 Btu/h (7038 W)
Air Conditioning
28,280 Btu/h (8288 W)
Electrical Outlets
One Live, Two On Ignition, One Live/Keyed
Mirrors
One Inside (Transport), Two Outside (Field)
Radio
Two Speakers and Antenna Factory Installed. Radio Dealer Installed
Speeds
Ground (mph or km/h), Engine (rpm), Knife (spm), Disc (rpm), Reel (rpm or
mph/km/h), Conveyor (Ref. No.)
Header Height, Angle, Float, Header Drive Load Gauge
Size
Drive
18.4 – 26 Bar, 18.4 – 26 Turf, 600-65 R28 Bar, 23.1 – 26 Turf, 580/70R26 Turf
Rear
7.5 – 16SL Single Rib, 10 - 16 Front Steer Tire
16.5L – 16.1 Rib Implement Flotation, Forked Caster
Pressure
Drive
Bar – 32 psi (221 kPa), Turf – 20 psi (138 kPa)
Rear
10 psi (69 kPa)
Dimensions
Refer to Section 4.3, Windrower Dimensions
Frame to Ground (Crop Clearance)
45.7 in. (1160 mm)
Weight
Base
9920 lb. (4500 kg)
Max GVW
21,500 (9750 kg)
Max CGVW
23,100 lb (10,480 kg)
NG Header Compatibility
A30-S & A40-D Auger, D50 Harvest Header, D60 Harvest Header Up To 40 Ft,
R80 & R85 Rotary Disc
NOTES: 1. Specifications and design are subject to change without notice or obligation to revise previously sold units.
2. Weights do not include options
.
