CDM / WCM ENGINE ERROR CODES
Form 169469/169470/169471 213 Revision C
E 1
R A N G E N O T A L L O W E D
HIGH range activated while in Cab forward (M150).
E 2
R T C N O T A L L O W E D
Return To Cut activated with the header off.
E 3
S I G N A L S N O T A L L O W E D
Turn Signals activated while in Cab forward.
E 4
H D R D R V N O T A L L O W E D
Header engage switch activated while in Engine forward.
E 5
R T C N O T A V A I L A B L E
Return To Cut activated while in Engine forward.
E 6
T E M P G A U G E S H O R T
Wiring / connection problem.
E 7
S P E E D S T I C K S H O R T
Wiring / connection problem.
E 8
H E A D E R E N A B L E S H O R T
Wiring / connection problem.
E 9
W C M E N A B L E S H O R T
Wiring / connection problem.
E 10
C D M I N T E R N A L E R R O R
Internal hardware or software problem.
E 11
C D M P O W E R U P
CDM Module did not power up correctly.
E 12
W C M P O W E R U P
WCM Module did not power up correctly.
E 13
F U E L S O L E N O I D
WCM Fuel solenoid output fault detected.
E 14 E114
D W A D R I V E P W M V 1 3
DWA Drive - PWM solenoid drive fault detected - short circuit / open circuit
E 15 E115
K N I F E D R I V E P W M V 8 Knife drive - PWM solenoid drive fault detected - short circuit / open circuit
E 16 E116
D R A P E R D R V P W M V 9 A
Draper Drive - PWM solenoid drive fault detected - short circuit / open circuit
E 17 E117
R E E L D R I V E P WM V 9 B
Reel Drive - PWM solenoid drive fault detected - short circuit / open circuit
E 19 E119
L O A D S E N S E V 1 6
Disc Block valve 16 - solenoid drive fault detected - short circuit / open circuit
E 21 E121
R E V E R S E R V 1 1 C
Reverser - Solenoid V14 fault detected - short circuit / open circuit
E 23 E123
R E V E R S E R V 1 1 A / B / 1 2 Reverser - Solenoid V11A, 11B or 12 fault detected - short circuit / open circuit
E 24 E124
D E C K S H F T R I G H T V 1 4 Right Deck Shift solenoid V14 fault detected - short circuit / open circuit
E 25 E125
D E C K S H F T L E F T V 1 5
Left Deck Shift solenoid V15 fault detected - short circuit / open circuit
E 26 E126
D W A U P V 2 C 2
DWA Raise solenoid V2C2 fault detected - short circuit / open circuit
E 27 E127
D W A D O W N V 4 C 2
DWA Lower solenoid V4C2 fault detected - - short circuit / open circuit
E 28 E128
T I L T R E T R A C T V 2 B
Tilt Retract solenoid V2B fault detected - short circuit / open circuit
E 29 E129
T I L T E X T E N D V 2 A
Tilt Extend solenoid V2A fault detected - short circuit / open circuit
E 30 E130
4 W A Y V A L V E V 6
4 Way valve solenoid V6 fault detected - short circuit / open circuit
E 31 E131
B Y P A S S V A L V E V 1
Bypass valve solenoid V1 fault detected - short circuit / open circuit
E 32 E132
H E A D E R U P / D O W N V 4 A
Header up / down solenoid V4A fault detected - short circuit / open circuit
E 33 E133
S C R E E N C L E A N E R S Screen cleaner output fault detected - short circuit / open circuit
E 34 E134
R I G H T S T O P L A M P
Right stop lamp output fault detected - short circuit / open circuit
E 35 E135
L E F T S T O P L A M P
Left stop lamp output fault detected - short circuit / open circuit
E 36 E136
R I G H T T U R N L A M P
Right turn lamp output fault detected - short circuit / open circuit
E 37 E137
L E F T T U R N L A M P
Left turn lamp output fault detected - short circuit / open circuit
E 38 E138
M A I N D R I V E V 1 0
Main header drive solenoid V10 fault detected - short circuit / open circuit
E 39 E139
M I D R A N G E V 5 B M200 Mid range solenoid V5B fault detected - short circuit / open circuit
E 40 E140
H I G H R A N G E V 5 A High range solenoid V5A fault detected - short circuit / open circuit
E 41 E141
R E E L A F T V 2 C
Reel aft solenoid V2C fault detected - short circuit / open circuit
E 42 E142
R E E L F O R E V 4 C
Reel fore solenoid V4C fault detected - short circuit / open circuit
E 43 E143
R E E L U P / D O W N V 4 B
Reel up / down solenoid V4B fault detected - short circuit / open circuit
E 44 E144
F L O A T R H S V 7 B
RHS float solenoid V7B fault detected - short circuit / open circuit
E 45 E145
F L O A T L H S V 7 A
LHS float solenoid V7A fault detected - short circuit / open circuit
E 46
S E N S O R V O L T S H I G H
Sensor voltage output high.
E 47
S E N S O R V O L T S L O W
Sensor voltage output low.
E 48
W C M O V E R T E M P
WCM over temp fault.
E 49
W C M L O W T E M P
WCM low temp fault.
E 50
B A T T + O U T O F R A N G E
System voltage above 16.5 VDC.
E 51 E151
D I S K D R I V E P W M V 8
Disk header drive solenoid V8 fault detected - short circuit / open circuit
E 64
H E A D E R O I L P R E S S U R E
Header drive charge pressure low (228)
E 65
K N I F E O V E R L O A D
Low knife speed detected < setpoint
E 66
# # . # L O W V O L T S
Low system voltage <11.5 VDC
E 67
T R A N S O I L P R E S S U R E
Drive supercharge pressure low (202)
E 68
T R A N S O I L T E M P
Trans oil temp >221 deg F.
E 69
E N G I N E A I R F I L T E R
Engine air filter plugged
E 70
H Y D R A U L I C F I L T E R
Hydraulic filter pressure too high. (227)
E 71
L O W H Y D R A U L I C O I L
Low hydraulic oil level sensor tripped (225)
E 72
# # . # H I G H V O L T S
System voltage above
E101
S P I E R R O R
J1939 Can error
E102
C A N E R R O R
J1939 Can error
E103
E E P R O M R E A D E R R O R
Internal error
E104
E E P R O M W R I T E E R R O R
Internal error
E105
T E M P S E N S O R E R R O R
Internal temperature sensor error.
E N G I N E O I L P R E S S U R E
Engine oil pressure warning.
E N G I N E T E M P E R A T U R E
Engine coolant temperature warning.
K N I F E S P D O V E R L O A D
Knife speed is < programmed setpoint while header engaged.
N O O P E R A T O R
Operator not detected in seat (~3 second delay before message)
N O H E A D E R
No header ID detected - not hooked up or wiring error.
L O C K S E A T B A S E
Seat base not detected in either Cab or Engine forward position.
D I S E N G A G E H E A D E R
Header engage switch on when ignition turned on.
x x x x S x x F x x C
Engine code configuration (Canbus)
C E N T E R S T E E R I N G
GSL or Pintal switches not closed with the key on / engine off.
N O T I N P A R K
GSL or Pintal switches not closed with the key on / engine off.
B R A K E O N
Engine running GSL out of "PARK" brake is still engaged.
P L A C E G S L I N T O " N "
GSL or Pintal switches not closed with the key on / engine off.
B R A K E S W F A I L U R E
Ignition on / engine not running - brake switch and relay closed
B R A K E O F F
Engine running - brake solenoid not activated.
C H E C K S E A T S W I T C H E S
System detects that both seat switches are active.
C A B F O R W A R D S W O N
If both awitches are detected to be activated then the display
E N G F O R W A R D S W O N
will alternately flash between these two messages.
CDM Error Codes for the M150 / 200 Tractor units
Error codes E52 to E63 not allocated
Error codes E73 to E100 not allocated
MISC INFORMATION / ERROR CODES
