M205 ENGINE ERROR CODES
Form 169469/169470/169471 215 Revision C
J1939 SPN
Description
J1939
SPN
J1939
FMI
Lamp
Color
Cummins
Engine
Code
Description
Engine Oil
Pressure
100
1 Red 415
Oil Pressure Low – Data Valid but Below Normal Operational
Range - Most Severe Level
2 Amber 435 Oil Pressure Sensor Circuit - Data Erratic, Intermittent, or Incorrect
3 Amber 135
Oil Pressure Sensor Circuit - Voltage Above Normal, or Shorted to
High Source
4 Amber 141
Oil Pressure Sensor Circuit - Voltage Below Normal, or Shorted to
Low Source
10 157 Engine oil pressure sensor 5V supply connection open circuit
17 N/A Low oil pressure - WARNING
18 Amber 143
Oil Pressure Low – Data Valid but Below Normal Operational
Range - Moderately Severe Level
Boost
Pressure
102
2 Amber 433
Intake Manifold Pressure Sensor Circuit - Data Erratic, Intermittent,
or Incorrect
3 Amber 122
Intake Manifold Pressure Sensor Circuit – Voltage Above Normal,
or Shorted to High Source
4 Amber 123
Intake Manifold Pressure Sensor Circuit – Voltage Below Normal,
or Shorted to Low Source
16 Amber 124
Intake Manifold 1 Pressure Data Valid but Above Normal –
Operational Range - Moderately Severe Level
Turbocharger
1 Speed
103
10 Amber 2345
Turbocharger speed invalid rate of change detected - Abnormal
Rate of Change
16 Amber 595
Turbocharger #1 Speed High - Data Valid but Above Normal
Operational Range – Moderately Severe Level
18 Amber 687
Turbocharger #1 Speed Low - Data Valid but Below Normal
Operational Range – Moderately Severe Level
Intake
Manifold #1
Temp
105
0 Red 155
Intake Manifold Air Temperature High – Data Valid but Above
Normal Operational Range - Most Severe Level
3 Amber 153
Intake Manifold Air Temperature Sensor Circuit - Voltage Above
Normal, or Shorted to High Source
4 Amber 154
Intake Manifold Air Temperature Sensor Circuit - Voltage Below
Normal, or Shorted to Low Source
15 None 2964
Intake Manifold Temperature High - Data Valid but Above Normal
Operational Range - Least Severe Level
16 Amber 488
Intake Manifold 1 Temperature - Data Valid but Above Normal
Operational Range - Moderately Severe Level
Inlet Manifold
Pressure
Sensor
106
3 135
Voltage above normal or shorted high
4 135 Voltage below normal or shorted low
10 135 Inlet Manifold Pressure Sensor 5V supply connection open circuit
Barometric
Pressure
108
2 Amber 295
Barometric Pressure Sensor Circuit - Data Erratic, Intermittent, or
Incorrect
3 Amber 221
Barometric Pressure Sensor Circuit – Voltage Above Normal, or
Shorted to High Source
4 Amber 222
Barometric Pressure Sensor Circuit – Voltage Below Normal, or
Shorted to Low Source
Coolant
Pressure
109
3 Amber 231
Coolant Pressure Sensor Circuit - Voltage Above Normal, or
Shorted to High Source
4 Amber 232
Coolant Pressure Sensor Circuit - Voltage Below Normal, or
Shorted to Low Source
18 Amber 233
Coolant Pressure - Data Valid but Below Normal Operational
Range - Moderately Severe Level
Engine
Coolant
Temperature
110
0 Red 151
Coolant Temperature Low - Data Valid but Above Normal
Operational Range - Most Severe Level
2 Amber 334
Coolant Temperature Sensor Circuit – Data Erratic, Intermittent, or
Incorrect
3 Amber 144
Coolant Temperature Sensor Circuit – Voltage Above Normal, or
Shorted to High Source
4 Amber 145
Coolant Temperature Sensor Circuit – Voltage Below Normal, or
Shorted to Low Source
15 None 2963
Engine Coolant Temperature High - Data Valid but Above Normal
Operational Range - Least Severe Level
16 Amber 146
Coolant Temperature High - Data Valid but Above Normal
Operational Range - Moderately Severe Level
