M205 ENGINE ERROR CODES
Form 169469/169470/169471 217 Revision C
J1939 SPN
Description
J1939
SPN
J1939
FMI
Lamp
Color
Cummins
Engine
Code
Description
14 Red 292
Auxiliary Temperature Sensor Input # 1 Circuit - Special
Instructions
Accelerator
Pedal Low Idle
Switch
558
2 Amber 431
Accelerator Pedal or Lever Idle Validation Circuit - Data Erratic,
Intermittent, or Incorrect
2 155 Data erratic, intermittent, or incorrect
4 Amber 551
Accelerator Pedal or Lever Idle Validation Circuit - Voltage Below
Normal, or Shorted to Low Source
13 Red 432
Accelerator Pedal or Lever Idle Validation Circuit - Out of
Calibration
System
Diagnostic
code # 1
611
3 Amber 2185
Sensor Supply Voltage #4 Circuit – Voltage Above Normal, or
Shorted to High Source
4 Amber 238
Sensor Supply Voltage #3 Circuit – Voltage Below Normal, or
Shorted to Low Source
Fuel Inlet
Meter Device
16 Amber 2292
Fuel Inlet Meter Device - Data Valid but Above Normal Operational
Range - Moderately Severe Level
18 Amber 2293
Fuel Inlet Meter Device flow demand lower than expected - Data
Valid but Below Normal Operational Range - Moderately Severe
Level
Electronic
Control
Module
31 Amber 757 Electronic Control Module data lost - Condition Exists
System
Diagnostic
Code # 2
612 2 Red 115
Engine Speed / Position Sensor Circuit lost both of two signals from
the magnetic pickup sensor - Data Erratic, Intermittent, or incorrect
Red Stop
Lamp
623 4 Amber 244
Red Stop lamp Driver Circuit - Voltage Below Normal, or Shorted to
Low Source
Power Supply 627 2 Amber 434
Power Lost without Ignition Off - Data Erratic, Intermittent, or
Incorrect
Controller #1 629 12 Red 111
Engine Control Module Critical internal failure - Bad intelligent
Device or Component
Calibration
Memory
630
2 Amber 341
Engine Control Module data lost - Data Erratic, Intermittent, or
Incorrect
13 Red 342 Electronic Calibration Code Incompatibility - Out of Calibration
31 Amber 2217 ECM Program Memory (RAM) Corruption - Condition Exists
Engine
software
631 2 415 Data incorrect
Fuel Control
Valve #1
633 31 Amber 2311 Fueling Actuator #1 Circuit Error – Condition Exists
Primary to
secondary
speed signal
637 11 143 Calibration fault
SAE J1939
Datalink
639
9 Amber 285
SAE J1939 Multiplexing PGN Timeout Error - Abnormal Update
Rate
13 Amber 286 SAE J1939 Multiplexing Configuration Error – Out of Calibration
Variable
Geometry
Turbocharger
641
3 Amber 2385
VGT Actuator Driver Circuit - Voltage Above Normal, or Shorted to
High Source
4 Amber 2384
VGT Actuator Driver Circuit - Voltage Below Normal, or Shorted to
Low Source
Turbo
Wastegate
646
5 177
Solenoid Current Low
6 177 Solenoid Current High
Injector
Cylinder #01
651
5 Amber 322
Injector Solenoid Cylinder #1 Circuit – Current Below Normal, or
Open Circuit
6 N/A Injector Current High
7 Amber 1139
Injector Cylinder #1 - Mechanical System Not Responding Properly
or Out of Adjustment
Injector
Cylinder #02
652
5 Amber 331
Injector Solenoid Cylinder #2 Circuit – Current Below Normal, or
Open Circuit
6 N/A Injector Current High
7 Amber 1141
Injector Cylinder #2 - Mechanical System Not Responding Properly
or Out of Adjustment
Injector
Cylinder #03
653 5 Amber 324
Injector Solenoid Cylinder #3 Circuit – Current Below Normal, or
Open Circuit
