OPERATOR’S STATION
Form 169469/169470/169471 37 Revision C
CAB-FORWARD - ENGINE RUNNING - HEADER DISENGAGED
(Scroll Through Display with CDM Switch or GSL Switch)
DISPLAY (Lower or Upper Line) DESCRIPTION
#####.# ENGINE HRS
Total Engine Operating Time.
#####.# HEADER HRS
Total Header Operating Time.
###.# SUB ACRES
###.# SUB HECTARES (If Metric)
Area Cut Since Last Reset. To Reset, Display SUB
ACRES On Lower Line and Hold Down Program Switch
Until Display Resets (5-7 Seconds).
###### TOTAL ACRES
###### TOTAL HECT
(If Metric)
Total Area Cut By Machine.
##.# HEADER HEIGHT
Distance Setting (00.0-10.0) Between Cutterbar &
Ground.
##.# HEADER ANGLE
Angle Setting (00.0-10.0) Header Relative to Ground.
##.# L FLOAT R ##.#
Float Setting (0.0-10.0).
### °C or F HYD OIL
Hydraulic Oil Temperature.
##.# VOLTS
Engine Electrical System Operating Voltage.
SCROLL
(Lower Line)
Displays Above Items After 2-3 Seconds. Press SELECT
to cancel.
