OPERATOR’S STATION
Form 169469/169470/169471 40 Revision C
CAB-FORWARD - ENGINE RUNNING - HEADER ENGAGED
DRAPER HEADER - INDEX SWITCH ON
(Scroll Through Display with CDM Switch or GSL Switch)
DISPLAY (Lower or Upper Line)
Total Engine Operating Time.
Total Header Operating Time.
##.# ACRES/HOUR
##.# HECTARES/HOUR
(If Metric)
Actual Cutting Rate In Acres (Hectares)/Hour.
###.# SUB HECTARES (If Metric)
Area Cut Since Last Reset. To Reset, Display SUB
ACRES On Lower Line and Hold Down Program Switch
Until Display Resets (5-7 Seconds).
###### TOTAL ACRES
(If Metric)
Total Area Cut By Machine.
.
(Sensor Disabled)
Reel Peripheral Speed Along With Ground Speed In
MPH or KPH.
Draper Speed Along With Ground Speed In MPH or
#### KNIFE SPEED
#### KNIFE SENSOR
(Sensor Disabled)
Knife Speed In Strokes Per Minute.
##.# HEADER HEIGHT
(Sensor Disabled)
Distance Setting (00.0-10.0) Between Cutterbar &
Ground.
##.# HEADER ANGLE
(Sensor Disabled)
Angle Setting (00.0-10.0) Header Relative To Ground.
Left and Right Float Setting (0.0-10.0).
LOAD|■■■■■_____| ####
(If Metric) #####
Bar Graph Representing Hydraulic Operating Pressure.
Full Scale Is Pre-Programmed Overload Pressure (2500
5000 psi).
If Sensor Disabled, LOAD Does Not Display. See Note.
Hydraulic Oil Temperature.
Engine Electrical System Operating Voltage.
SCROLL
SUB-MENU (Lower Line Only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■■■■■■■■■| ####
##.## REEL IND
##.# DRAP INDX
Displays Sub-Menu After 2-3 Seconds. Press SELECT
to cancel.
Scroll Through Sub-Menu Display with CDM Switch
(Lower Line)
Reel Speed Drops Below Programmed Set-Point.
(Lower Line)
Reel Speed At Zero Ground Speed.
NOTE: The LOAD sensor to monitor knife/conditioner circuit pressure is factory installed. To monitor reel/draper circuit
pressure, relocate sensor as per Instruction 169031 which is available through your dealer.
