WINDROWER OPERATION
Form 169469/169470/169471 59 Revision C
g. Normal Start - engine temperature above 60°F
(16°C):
1. Set throttle (D) to start position – fully back.
IMPORTANT
The machine gauges and instruments
provide important information about
machine operation and condition.
Familiarize yourself with the gauges and
monitor them carefully during start-up
operation. Refer to Section 5.15, ENGINE
CONTROLS/GAUGES.
CAUTION
Be sure the area is clear of other persons,
pets etc. before proceeding.
2. Sound horn three times.
3. Turn ignition key (E) to RUN position.
4. Single loud tone sounds, engine warning
lights illuminate and CDM displays HDR
DISENGAGED or HEADER ENGAGED and
IN PARK.
5. Turn ignition key to START position until
engine starts and then release key. Tone
ceases and warning lights go out. CDM
displays programmed header data for 5
seconds if attached and then returns to
previous display.
IMPORTANT
Do not operate starter for longer than 15
seconds at a time. If engine does not start,
wait at least two minutes before trying
again. After the third 15 second crank
attempt, allow solenoid to cool for 10
minutes before further cranking attempts.
If engine still does not start, refer to
Trouble Shooting section.
WARNING
If starter engages with steering wheel
unlocked, ground speed lever out of neutral,
or header clutch engaged, DO NOT START
ENGINE. See your dealer.
h. Cold Start - engine temperature below 40°F
(5°C)
1. Follow procedure for Normal Start.
2. Engine will cycle through a period where it
appears to labour until engine warms up.
NOTE
Throttle is non-responsive during this time
as engine is in “WARM UP” mode. This
mode will last from 30 seconds to 3
minutes depending on temperature. After
engine has stabilized and is idling
normally, throttle becomes active.
IMPORTANT
Do not operate engine above 1500 rpm
until engine temperature gauge is above
100°F (40°C).
WARNING
If starter engages with steering wheel
unlocked, ground speed lever out of neutral,
or header clutch engaged, DO NOT START
ENGINE. See your windrower dealer.
6.3.5.2 Engine Warm-Up
Allow engine to run
with throttle lever (D)
at or near low idle
position until
temperature gauge
reaches approximately
100°F (40°C).
