WINDROWER OPERATION
Form 169469/169470/169471 69 Revision C
d. Position bracket (A), and install bolts (B). The
two shorter bolts are installed at the back
inboard locations.
e. Install bottom bolts (C).
f. Tighten bolts as follows:
1. Snug bottom bolts (C).
2. Tighten and torque back bolts (B) to 330
ft∙lbf (447 N∙m).
3. Tighten and torque bottom bolts (C) to 330
ft∙lbf (447 N∙m).
g. Lower Windrower to ground.
IMPORTANT
Re-torque bolts after first 5, and 10 hours
of operation.
