Introduction
This document outlines all site requirements needed to install a Spraytec system.
Ensure that all site requirements are fulfilled before the Malvern Instruments
engineer arrives to install and commission your system.
Environmental conditions
When choosing a site for the system, ensure the following conditions are met.
The following guidelines apply to both instrument types:
.
Avoid passing electrical cables through areas where liquids can be spilt.
.
Rooms must be well ventilated if noxious sprays are used.
#
Warning!
The laboratory Spraytec instrument and its accessories are intended for indoor
use only. For this instrument:
.
Position the instrument away from strong light sources (e.g. windows).
.
Position the instrument away from strong heat sources (e.g. radiators).
.
The bench that carries the system must be horizontal and vibration free. It
must also be capable of supporting the weight of the system. This table lists
the weights of the system components:
Spraytec 36kg (short X-bar), 37kg (long X-bar)
NSS 5.3kg
Air purge
(passive air supply)
6kg
Extractor 14kg
Computer and Printer See manufacturer’s documentation
APPENDIX C
Spraytec Page C.1
Do not position the system where it obstructs power sockets; they may
need to be disconnected during an emergency.
