Introduction
This chapter introduces the Spraytec hardware components. It provides:
.
A summary of the key hardware components.
.
For each key component, a description of its main parts.
The software package is described in the following chapter.
Key components
This diagram shows the key components of a typical complete system:
These are:
+
Spraytec instrument.
,
External Power Supply Unit (PSU).
-
Control computer running the Spraytec software.
The following sections describe these components. Accessories are described in
the Spraytec Accessories User Manual.
CHAPTER 3
Spraytec Page 3.1
1
2
3
ILL 7421
