The wet environment Spraytec is suitable for indoor use and wet
environments.
The system is designed to be stored and operated in the following conditions:
Operating temperature
+
15 to
+
40 °C (
+
50 to 95 °F)
Humidity 35 to 80% (non-condensing)
Altitude Up to 2000m
Pollution degree 2 (IEC 60664)
Enclosure (with all cables and plugs
fitted)
IP65 (IEC 60529)
This excludes the external PSU, which must be
located outside of the spray zone
Overvoltage Category II (IEC 60664)
Mains supply voltage fluctuations ±10% of nominal voltage
Storage
Store the instrument in a dry place where no mould will form.
Space required
Dimensions of all components of the system are given below.
Component Width Depth Height
Spraytec 950mm or
1400mm
550mm 610mm
NSS 170mm 390mm 260mm
Air purge 350mm 160mm 350mm
Extractor 290mm 360mm 390mm
Computer and printer See manufacturer’s documentation
APPENDIX C
Spraytec
Page C.2 MAN 0368
