The Spraytec instrument
The Spraytec instrument is shown below:
The Spraytec has the following major components:
+
Optical support bench (X-bar).
,
Transmitter.
-
Receiver.
.
Lens (attached to the Receiver).
/
Power switch.
This section summarises the functions of these components.
There are two versions of the instrument:
.
Standard – identified by a green label on the Receiver cover.
.
High speed – identified by a red 10K label on the Receiver cover. This is
only available as a 'feature key' option/upgrade.
CHAPTER 3
Spraytec
Page 3.2 MAN 0368
1
3
4
2
5
ILL 7422
