Malvern Instruments Spraytec - Dimensions; Laser; Optical Unit

Specification
Dimensions
Dimension Short X-bar Long X-bar
Length 950mm 1400mm
Width 550mm 550mm
Height 610mm 610mm
Weight 36kg 37kg
Laser
CDRH and IEC60825-1 compliant Class 3R laser product
Max. output power <5mW
Beam diameter
(measurement zone)
10mm (1/e²)
Beam wavelength 632.8nm
Optical unit
Measurement principle Laser diffraction.
Size range 0.1µm to 2000µm
Lens ranges
300 mm lens
750 mm lens
0.1 – 900mm (Dv50: 0.5 – 600mm)
2 – 2000mm (Dv50: 5 – 1600mm)
Working range
300 mm lens
750 mm lens
150 mm minimum working distance.
500 mm minimum working distance.
APPENDIX B
Spraytec Page B.1
