Move the computer equipment by following the manufacturer’s instruc
-
tions.
.
At the new location reverse the above procedure.
#
Warning!
Longer distance movements
If moving the system a significant distance, for example between sites:
.
Power off all components.
.
Disconnect the mains power cable and cables between components and to
accessories.
.
Remove the Transmitter and Receiver from the X-bar, and the lens from
the Receiver.
.
Pack all components, if possible in their original packaging.
.
Do not remove the feet from the X-bar. This is important as it is diffi-
cult to replace them in exactly the same position.
.
Disconnect and pack the computer and monitors, following the manufac-
turer’s instructions.
.
At the new location, reverse the above procedure.
.
Set up all computer connections, following the manufacturer’s instructions.
Adjusting the Spraytec feet
For the laboratory Spraytec the X-bar must be at 12°. To achieve this adjust the
feet as follows:
.
Both front feet – screw both feet in fully home. These do not use spacers.
.
Back right foot – use a spacer and screw the foot fully home.
.
Back left – this is the adjustable foot. It needs no spacer; instead use the nut
to lock it in place once the height is correct. Adjust it until the instrument
does not rock.
The wet environment Spraytec has simpler feet. Only adjust these if the
instrument rocks when placed on a surface.
APPENDIX E
Spraytec
Page E.2 MAN 0368
This product must be connected to a protective earth.
