Select one or more records using the mouse as described above then
right-click and select Zoom in to Selection. There is also a Zoom Out
option to undo this.
Keyboard shortcuts
Use the left arrow and right arrow keys to move the selector bar by one record.
These keys can be combined with:
.
The Shift key – to move the bar by 10 records.
.
The Ctrl key – to move the bar by 100 records.
.
Both Shift+Ctrl – to move the bar by 1000 records.
'
Note
.
If the time axis duration is very long compared to the time between
records, the above numbers are approximate.
Other key commands for size history windows are:
.
Home – moves the time axis so the first measurement in the file is at the
start of the chart (zero relative time).
.
End – moves the time axis to show the last measurement in the file is at the
right-hand end of the chart.
.
Page Up – moves the selector bar to the first record of the previous event
(if the measurement is split into events).
.
Page Down – moves the selector bar to the first record of the next event
(if the measurement is split into events).
.
Number pad “+” – zooms the display to show the selected range of re
-
cords ('Zoom in to selection' on the right-click menu).
.
Number pad “-” – zooms the display to show all of the records ('Zoom
out' on the right-click menu).
Changing the display options
To change the chart title, axes, derived parameters shown, colours used, line
symbols, etc, right-click on the Size History view and select Properties to display
the Size History Display Setup dialogue:
CHAPTER 4
Spraytec Page 4.7
